YZ 3S Injection Molding Machines (Variable Pump 90~320T)

Clamping Unit

Strictly check the parallelism between fixed platen and movable platen, as well as the consistency of clamping force withstood by four tie bars.

Contact Now

Centering Bearing of Injection

Unique injection tail platen,
with a centering bearing,
enhances plasticizing posting,
reducing the radial run-out,
enhancing the durability of screw & bearing while plasticizing is running.

Contact Now

Screw Plasticizing

Professional screw design, and melt density balance, ensure the physical character & weight of products. Screw compression ratio, L/D ratio, ensure material mixing & cutting completely, And minimized the difference between actual and setting temperature.

Contact Now

– OTHER SYSTEMS –

Screw Tip Assembly		Linear Guide

Electroplated high hardness screw sets, residual material easy to clean, prevent black spots, miscellaneous colors, and corrosion of screw.		Linear guide rails with a thickened frame, which achieve the lowest mechanical movement resistance & support high-speed injection actions. And repeated injection position accuracy to be 0.1mm tolerance.
Copper-Alloy Slides		Large-Diameter Oil Circuit

The movable platen has copper-alloy double slides that reduce resistance when opening and closing the mold at high speed, ensuring long-lasting mechanical movement.		Adopt large-diameter oil circuit with low internal resistance control method to improve the response tempo and repeat accuracy of action.

3S Series Variable Pump Machines Parameter

Discription	UNIT	YZ90B-ⅢS				YZ120B-ⅢS				YZ160B-ⅢS			YZ200B-ⅢS			YZ260B-ⅢS			YZ320B-ⅢS
International Standard Model		296/900				441/1200				660/1600			912/2000			1322/2600			1992/3200
Injection Unit
Screw Type		U	A	B	C	U	A	B	C	A	B	C	A	B	C	A	B	C	A	B	C
Screw Diameter	mm	28	31	36	42	31	36	42	46	42	46	52	46	52	60	52	60	67	60	67	75
Screw L/D Ratio	L:D	20.5	23.2	20	17.1	20	23.4	20.1	18.3	22	20.1	17.8	23.3	20.6	17.8	24.6	21.3	19.1	24.6	22	19.7
Injection Volume	cc	100	122	165	224	142	191	260	312	292	350	448	397	507	675	586	780	973	910	1135	1422
Injection Weight	g	91	111	150	204	129	174	237	284	266	319	407	361	461	614	533	709	884	827	1031	1292
	oz	3.2	3.9	5.2	7.1	4.5	6.1	8.3	9.9	9.3	11.2	14.2	12.6	16.1	21.5	18.6	24.8	30.9	29	36.1	45.2
Injection Pressure	Mpa	297	242	180	132	310	230	169	141	226	188	147	230	180	135	226	169	136	219	175	140
Injection Rate	cm³/sec	53	65	88	119	62	83	113	136	106	127	162	130	166	221	189	251	313	293	366	458
Injection Stroke	mm	162				188				211			239			276			322
Screw Speed	rpm	165				172				166			156			167			190
Clamping System
Clamping Force	kN	900				1200				1600			2000			2600			3200
Clamping Stroke	mm	320				360				425			485			540			620
Max opening of the Mold	mm	640				810				925			1035			1140			1280
Min-Max Mold Thickness	mm	130-360				145-450				160-500			180-550			195-600			220-660
Internal Range of Four Tie Bars	mm	360×360				410×410				460×460			510×510			575×575			655*655
Mold Dimension	mm	550×550				600×600				670×670			765×765			840×840			940*940
Diameter of Mold Positioning Hole	mm	Φ100H8				Φ125H8				Φ125H8			Φ125H8			Φ160H8			Φ160H8
Ejector Force	kN	23				34				42			67			77			77
Ejector Stroke	mm	80				120				140			150			180			180
Ejector Pin Quantity	pcs	1				5				5			5			13			13
Power unit
System Pressure	Mpa	14.5				17.5				17.5			17.5			17.5			17.5
Oil Pump Motor	kW	7.5				11				15			18.5			22			42
Heating Power	kW	6.5				9.8				10.9			14.0			17.7			20.9
Temperature Control Zone	segment	5				5				5			5			5			5
General
Oil Tank Capacity	L	130				170				210			250			370			450
Machine Weight	Tons	3.1				3.8				4.7			6.2			8.5			11.1
Overall Dimension (LxWxH)	mxmxm	3.84×1.08×1.76				4.3×1.16×1.85				4.59×1.29×1.97			5.19×1.36×1.94			6.13×1.49×2.06			6.65×1.60×2.18

Standard configuration
Clamping Unit
Five-point inclined-row hyperbolic elbow mold clamping mechanism	Euro ejector structure	Movable platen hydraulic core-pulling device:90T-160T with 1 set of core oil circuit boards (no valve);200T-320T with 2 sets of core oil circuit boards, 1 assembly valve, another group without valve;400T and above With 2 sets of core-pulling device
Mechanical and electrical safety interlock	Sensor switch at ejector backward endpoint with adjustable position	Concentrated automatic lubrication system of clamping unit (lubricating oil for 90T-160T, grease oil for 200T and above)
5-segment mold clamping pressure, speed, position control	Hydraulic motor gear modulation structure	Lubricating oil drip tray
6-segment for mold opening pressure, speed and position control	Automatic modulation function (position/pressure mode)	Mold cooling water device:models of 200T and below have six groups of D12 water connectors, models of 260T and above have 10 groups of D12 water connectors
Low-pressure mold protection function	Mold can be adjusted in any position (90T ~ 320T)	Standard manipulator equipped with junction boxes and a set of air valve connectors, without a valve
Differential motion device for quick clamping	Max. and Min. limit switches for mold stroke
Electronic ruler control of mold opening and closing positions	High-strength ductile iron used in platens and toggles
Sensor switch at clamping endpoint	Adjustable wear-resistant slides and guide rails for movable platen
2-segment ejector pressure, speed, position control	Product hopper (90T ~ 260T)
Multiple ejector control modes (stay, fixed, vibrate)	Photoelectric switch for product detection (90T ~ 260T)
Electronic ruler control of ejector positions	Transparent windows on fixed cover plates in front of and behind the mold
Injection Unit
Double -cylinder balance injection structure	Injection switch to pressure keeping function (time/position/time&position)	Screw barrel insulation function
Linear slide table structure (equipped for 200T and above models with double injection oil cylinders)	Injection location monitoring function	Plasticizing temperature controlled by computer PID
Hard chrome plated screw and nitrided barrel	Electronic ruler control of injection position	Heat shield of screw barrel
Hard chrome plated injection nozzle and flange	Anti-cold start protection of screw	Adjustable plasticizing back pressure (standard digital back pressure for models of 480T and above)
Hard chrome plated screw tip assembly	Three modes of injection backward selection function (after the storage / after the injection / before the mold opening )	Plasticizing speed display
Injection nozzle extends 50mm above the platen	Spillage prevention	Injection nozzle centering tuning device
6-segment injection pressure, speed, position control	Automatic material cleaning	Adjustable hopper
5-segment stress pressure, speed, position control	Screw pre-plasticizing device driven by hydraulic motor	Stainless steel hopper (Non-dry one)
5-segment storage pressure, speed, position control	Automatic heating function of screw barrel	Injection table with non-slip patterned aluminum plate
Hydraulic Control Unit	Control Unit	Other Units
System pressure and flow closed-loop control (servo system)	LED screen control computer for injection molding machines	Randomly equipped with Great Wall / KunLun hydraulic oil
High -efficiency gear pump (servo system)	Parameter data protection	A set of adjustable shock absorbers
Imported seals and valve parts	Mold parameter storage function (500 sets)	A toolbox with a normal set of tools
Liquid level gauge of oil tank	Real -time monitoring shows the operation of each action	2 precision oil filters
Precision oil filter	Alarms for abnormal conditions	Operation manual
Oil absorption filter	Display of plasticizing temperature deviation
Hydraulic oil cooler	SPC production management function, 5000 modulus data storage memory
Explosion-proof chain of exposed high -pressure oil pipes	Electrical interface for robot arms (spare contact for IO board)
	Emergency stop buttons on the front and back sides
	Three-color alarm light with buzzer
	380V32A five-hole waterproof socket 2pcs,380V16A five-hole waterproof socket 1pcs
	220V single-phase five-hole socket 1pcs (with a waterproof cap)

Optional devices
Clamping Unit	Injection Unit	Control unit
Movable platen core-pulling device(1-3sets)	Screws & barrels for specified raw materials	Larger engine power
Air blowing device (1-4sets)	Nozzles extended by 50/100/150 mm	Larger cooler
Mold positioning circle	Nozzle extends 50/100/150 mm above the platen	Drying hopper
Rotate pusher device	Pneumatic one-way nozzle	Increase the cooling water connectors (10 groups)
Ejector power increased by one level	Hydraulic one-way nozzle	Cooling water device with quick connectors (D10/D12/D16)
Incrase mold thickness	Spring nozzle	Add an external socket (380V/220V)
Platen insulation board	Nozzle protection cover	Oil temperature detection function
T-slot platen	CNC plasticizing back pressure for 400T and below models	Oil temperature preheating function
Mold temperature control	Plasticizing motor power increased by 1 - 2 levels	Hydraulic safety lock
Mold needle valve function	High temperature heating ring for barrel (up to 500 ℃)	Self -sealed oil absorption filter
Ejection synchronized with mold opening	Nano-infrared heating ring for barrel	Security module device
Core pulling synchronized with mold opening	Ceramic heating ring for barrel	An energy meter and a current transformer
Plasticizing synchronized with mold opening	Proportional pressure control injection unit (servo system)	Cooling water flow meter
Opening and closing mold control with high response ratio
