YZ 3S Injection Molding Machines (Servo Motor 320~650T)

Clamping Unit

Strictly check the parallelism between fixed platen and movable platen, as well as the consistency of clamping force withstood by four tie bars.

Contact Now

Centering Bearing of Injection

Unique injection tail platen,
with a centering bearing,
enhances plasticizing posting,
reducing the radial run-out,
enhancing the durability of screw & bearing while plasticizing is running.

Contact Now

Screw Plasticizing

Professional screw design, and melt density balance, ensure the physical character & weight of products. Screw compression ratio, L/D ratio, ensure material mixing & cutting completely, And minimized the difference between actual and setting temperature.

Contact Now

– OTHER SYSTEMS –

Screw Tip Assembly		Linear Guide

Electroplated high hardness screw sets, residual material easy to clean, prevent black spots, miscellaneous colors, and corrosion of screw.		Linear guide rails with a thickened frame, which achieve the lowest mechanical movement resistance & support high-speed injection actions. And repeated injection position accuracy to be 0.1mm tolerance.
Copper-Alloy Slides		Large-Diameter Oil Circuit

The movable platen has copper-alloy double slides that reduce resistance when opening and closing the mold at high speed, ensuring long-lasting mechanical movement.		Adopt large-diameter oil circuit with low internal resistance control method to improve the response tempo and repeat accuracy of action.

3S Series Servo Motor Machines Parameter

Discription	UNIT	YZ320S-ⅢS			YZ400S-ⅢS			YZ480S-ⅢS			YZ560S-ⅢS			YZ650S-ⅢS
International Standard Model		1992/3200			2646/4000			3695/4800			4664/5600			5085/6500
Injection Unit
Screw Type		A	B	C	A	B	C	A	B	C	A	B	C	A	B	C
Screw Diameter	mm	60	67	75	67	75	83	75	83	90	80	88	95	83	90	98
Screw L/D Ratio	L:D	24.6	22.0	19.7	23.8	21.3	19.2	23.3	21.0	19.4	23.1	21.0	19.5	24.0	22.1	20.3
Injection Volume	cc	910	1135	1422	1219	1528	1871	1766	2163	2543	2236	2705	3153	2352	2766	3280
Injection Weight	g	827	1031	1292	1108	1389	1701	1606	1966	2312	2032	2459	2866	2138	2514	2981
	oz	29.0	36.1	45.2	38.8	48.6	59.5	56.2	68.8	80.9	71.1	86.1	100.3	74.8	88.0	104.3
Injection Speed	mm/s	104			105			101			101			100
Injection Rate	cm³/sec	293	366	458	370	463	567	445	545	641	506	612	713	535	629	745
Injection Pressure	Mpa	219	175	140	217	173	141	209	171	145	208	172	148	216	184	155
Injection Stroke	mm	322			346			400			445			435
Screw Speed	rpm	183			157			145			150			150
Clamping System
Clamping Force	kN	3200			4000			4800			5600			6500
Clamping Stroke	mm	620			720			770			835			920
Max Opening of the Mold	mm	1280			1470			1590			1685			1830
Min-Max Mold Thickness	mm	220-660			250-750			275-820			330-850			350-910
Internal Range of Four Tie Bars	mm	655×655			730×730			810×810			855×855			910×910
Mold Dimension	mm	940×940			1050×1050			1155×1155			1210×1210			1320×1320
Diameter of Mold Positioning Hole	mm	Φ160H8			Φ200H8			Φ200H8			Φ200H8			Φ200H8
Ejector Force	kN	77			111			111			166			182
Ejector Stroke	mm	180			215			250			250			265
Ejector Pin Quantity	pcs	13			13			13			13			13
Power unit
System Pressure	Mpa	17.5			17.5			17.5			17.5			17.5
Oil Pump Motor	kW	60			65			70			75			37+60
Heating Power	kW	20.9			21.6			30.0			30.0			36.0
Temperature Control Zone	segment	5			5			5			6			6
General
Oil Tank Capacity	L	540			630			760			760			910
Machine Weight	Tons	11.1			14.5			18.0			20.5			27.0
Overall Dimension (LxWxH)	mxmxm	6.65×1.60×2.18			7.43×1.65×2.15			8.2×1.82×2.19			8.32×1.95×2.19			9.55×1.96×2.67

Standard configuration
Clamping Unit
Five-point inclined-row hyperbolic elbow mold clamping mechanism	Euro ejector structure	Movable platen hydraulic core-pulling device:90T-160T with 1 set of core oil circuit boards (no valve);200T-320T with 2 sets of core oil circuit boards, 1 assembly valve, another group without valve;400T and above With 2 sets of core-pulling device
Mechanical and electrical safety interlock	Sensor switch at ejector backward endpoint with adjustable position	Concentrated automatic lubrication system of clamping unit (lubricating oil for 90T-160T, grease oil for 200T and above)
5-segment mold clamping pressure, speed, position control	Hydraulic motor gear modulation structure	Lubricating oil drip tray
6-segment for mold opening pressure, speed and position control	Automatic modulation function (position/pressure mode)	Mold cooling water device:models of 200T and below have six groups of D12 water connectors, models of 260T and above have 10 groups of D12 water connectors
Low-pressure mold protection function	Mold can be adjusted in any position (90T ~ 320T)	Standard manipulator equipped with junction boxes and a set of air valve connectors, without a valve
Differential motion device for quick clamping	Max. and Min. limit switches for mold stroke
Electronic ruler control of mold opening and closing positions	High-strength ductile iron used in platens and toggles
Sensor switch at clamping endpoint	Adjustable wear-resistant slides and guide rails for movable platen
2-segment ejector pressure, speed, position control	Product hopper (90T ~ 260T)
Multiple ejector control modes (stay, fixed, vibrate)	Photoelectric switch for product detection (90T ~ 260T)
Electronic ruler control of ejector positions	Transparent windows on fixed cover plates in front of and behind the mold
Injection Unit
Double -cylinder balance injection structure	Injection switch to pressure keeping function (time/position/time&position)	Screw barrel insulation function
Linear slide table structure (equipped for 200T and above models with double injection oil cylinders)	Injection location monitoring function	Plasticizing temperature controlled by computer PID
Hard chrome plated screw and nitrided barrel	Electronic ruler control of injection position	Heat shield of screw barrel
Hard chrome plated injection nozzle and flange	Anti-cold start protection of screw	Adjustable plasticizing back pressure (standard digital back pressure for models of 480T and above)
Hard chrome plated screw tip assembly	Three modes of injection backward selection function (after the storage / after the injection / before the mold opening )	Plasticizing speed display
Injection nozzle extends 50mm above the platen	Spillage prevention	Injection nozzle centering tuning device
6-segment injection pressure, speed, position control	Automatic material cleaning	Adjustable hopper
5-segment stress pressure, speed, position control	Screw pre-plasticizing device driven by hydraulic motor	Stainless steel hopper (Non-dry one)
5-segment storage pressure, speed, position control	Automatic heating function of screw barrel	Injection table with non-slip patterned aluminum plate
Hydraulic Control Unit	Control Unit	Other Units
System pressure and flow closed-loop control (servo system)	LED screen control computer for injection molding machines	Randomly equipped with Great Wall / KunLun hydraulic oil
High -efficiency gear pump (servo system)	Parameter data protection	A set of adjustable shock absorbers
Imported seals and valve parts	Mold parameter storage function (500 sets)	A toolbox with a normal set of tools
Liquid level gauge of oil tank	Real -time monitoring shows the operation of each action	2 precision oil filters
Precision oil filter	Alarms for abnormal conditions	Operation manual
Oil absorption filter	Display of plasticizing temperature deviation
Hydraulic oil cooler	SPC production management function, 5000 modulus data storage memory
Explosion-proof chain of exposed high -pressure oil pipes	Electrical interface for robot arms (spare contact for IO board)
	Emergency stop buttons on the front and back sides
	Three-color alarm light with buzzer
	380V32A five-hole waterproof socket 2pcs,380V16A five-hole waterproof socket 1pcs
	220V single-phase five-hole socket 1pcs (with a waterproof cap)

Optional devices
Clamping Unit	Injection Unit	Control unit
Movable platen core-pulling device(1-3sets)	Screws & barrels for specified raw materials	Larger engine power
Air blowing device (1-4sets)	Nozzles extended by 50/100/150 mm	Larger cooler
Mold positioning circle	Nozzle extends 50/100/150 mm above the platen	Drying hopper
Rotate pusher device	Pneumatic one-way nozzle	Increase the cooling water connectors (10 groups)
Ejector power increased by one level	Hydraulic one-way nozzle	Cooling water device with quick connectors (D10/D12/D16)
Incrase mold thickness	Spring nozzle	Add an external socket (380V/220V)
Platen insulation board	Nozzle protection cover	Oil temperature detection function
T-slot platen	CNC plasticizing back pressure for 400T and below models	Oil temperature preheating function
Mold temperature control	Plasticizing motor power increased by 1 - 2 levels	Hydraulic safety lock
Mold needle valve function	High temperature heating ring for barrel (up to 500 ℃)	Self -sealed oil absorption filter
Ejection synchronized with mold opening	Nano-infrared heating ring for barrel	Security module device
Core pulling synchronized with mold opening	Ceramic heating ring for barrel	An energy meter and a current transformer
Plasticizing synchronized with mold opening	Proportional pressure control injection unit (servo system)	Cooling water flow meter
Opening and closing mold control with high response ratio
